9200-8E Lsi Logic 6Gb 8Port PCI-Express Sas/Sata Host Bus Adapter Controller

9200-8E Technical Specifications

Lsi Logic 6Gb 8Port PCI-Express Sas/Sata Host Bus Adapter Controller

Manufacturer: Lsi Logic
Part Number or SKU# 9200-8E
Product Type: Controller
Product Name: SAS-SATA
Storage Connectivity Data Transfer Rates
8 Ports 6gb/s Sas 2.0 Compliant
Host Bus : X8 Lane, Pci Express 2.0 Compliant
Pci Data Burst Transfer Rates : Half Duplex
x8, Pcie, 4000 Mb/s
Dimensions
+12v ±10%
Low Profile (2. 6″ X 6.6″)
Cable Support : Passive Copper
Pci Card Type : 3.3 V Add-in Card
Operating Voltage : +12v +/-8% 3.3v +/-8%
Pci Power (nominal) : 8 W Typical (airflow Min 200 Lfm)
Device Support : 512 Non-raid Sas/sata Devices
