8871KGU Technical Specifications
Lenovo System X3650 M5 8871, 2U Rack Mountable Server
GENERAL INFORMATION
Type : Server
Part: 8871KGU
Product Form Factor : Rack-Mountable 2U
Embedded Security : Trusted Platform Module (T pm 1.2 And T pm 2.0)
Server Scalability : 2-Way
Front Accessible Bays Qty : 1
Hot-Swap Bays Qty : 8
PROCESSOR / CHIPSET :
Cpu : Intel Xeon E5-2630v4 / 2.2 GHz
Max Turbo Speed : 3.1 Ghz
Number Of Cores : 10-Core
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Processor Main Features : Hyper-Threading Technology, Intel Turbo Boost Technology : 2
Chipset Type : Intel C612
CACHE MEMORY :
Installed Size : 25 Mb
Cache Per Processor : 25 Mb
RAM :
Installed Size : 16 Gb / 768 Gb (Max)
Technology : Ddr4 Sdram – Ecc
Rated Memory Speed : 2400 Mhz
Memory Specification Compliance : Pc4-19200
Form Factor : Dimm 288-Pin
Features : Registered, Memory Mirroring, Memory Sparing, Quad Channel Memory Architecture
Configuration Features : 1 X 16 Gb
Ram Supported : 1.5 Tb Load-Reduced ¦ 768 Gb Registered
STORAGE CONTROLLER:
Type : 1 X Sas
Controller Interface Type : Sata 6gb/S / Sas 12gb/S
Storage Controller Name : Serveraid M5210
Raid Level : Raid 0, Raid 1, Raid 10
GRAPHICS CONTROLLER :
Graphics Processor : Matrox G200er2
Video Memory : 16 Mb
Video Interfaces : Vga
NETWORKING :
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller : Broadcom Bcm5719
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Management Module Ii (Imm2)
POWER :
Device Type : Power Supply – Hot-Plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (With Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Nominal Voltage : Ac 120/230 V (50/60 Hz)
Power Provided : 900 Watt
80 Plus Certification : 80 Plus Platinum
