881787-K21 Technical Specifications
HPE internal hard drive 3.5″ 12000 GB Serial SATA
General
Device Type: Hard Drive – Hot Swap
Capacity: 12 TB
Form Factor: 3.5 inch LFF
Interface: SATA 6Gb/s
Bytes per Sector: 512
Features: Advanced format 512e, Helium technology, Digitally Signed Firmware
Carrier Type: Low Profile Carrier (LPC)
Plug Type: Hot Plug
Workload Type: Midline
Bundled with: HPE Low Profile Carrier
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Performance
Drive Transfer Rate: 6 Gb/sec (external)
Seek Time: 8 ms (average) / 16 ms (max)
Spindle Speed: 7200 RPM
Track-to-Track Seek Time: 0.23 ms
Power Idle Time: 5.50 Watt
Power Random Read: 6.10 Watt
Power Random Write: 6.10 Watt
Power Sequential Read: 7.00 Watt
Power Sequential Write: 6.80 Watt
OD Media Rate, Max Sequential Throughput (MiB/s): 235
128Kib Random Read (IOPs): 105
128Kib Random 70% RD/ 30% WT (IOPs): 115
128Kib Random 50% RD/ 50% WT (IOPs): 125
Expansion & Connectivity
Compatible Bay: 3.5″ LFF
Interfaces: 1 x SATA 6 Gb/s
Product Dimensions
Height: 1.00 inch
Width: 4.20 inch
Depth: 6.20 inch
