Refurbished 877756-B21 Technical Specifications
HPE 960GB SATA 6GBPS 3.5inch LFF Read Intensive Hot Swap LPC Digitally Signed Firmware Solid State Drive For Proliant Gen9 And Gen10 Servers
MAIN SPECIFICATIONS:
PRODUCT DESCRIPTION : HPE READ INTENSIVE – SOLID STATE DRIVE – 960 GB – SATA 6GB/S
TYPE : SOLID STATE DRIVE (SSD) – HOT SWAP
CAPACITY : 960GB
NAND FLASH MEMORY TYPE : MULTI-LEVEL CELL (MLC)
FORM FACTOR : 3.5 inch LFF
INTERFACE : SATA 6GB/S
DATA TRANSFER RATE : 600 MBPS
FEATURES : DIGITALLY SIGNED FIRMWARE, HPE SMARTSSD WEAR GAUGE
DIMENSIONS (WXDXH) : 0.3 IN
BUNDLED WITH : HPE LOW PROFILE CONVERTER
DESIGNED FOR : PROLIANT ML110 GEN9 (3.5), ML110 GEN9 BASE (3.5), ML110 GEN9 ENTRY (3.5), ML350 GEN10 (3.5), ML350 GEN10 BASE (3.5), ML350 GEN10 ENTRY (3.5), ML350 GEN10 PERFORMANCE (3.5), ML350 GEN10 SUB-ENTRY (3.5), XL170R GEN10 (3.5), XL190R GEN10 (3.5)
EXTENDED SPECIFICATIONS:
DEVICE TYPE : SOLID STATE DRIVE – HOT-SWAP
CAPACITY : 960 GB
NAND FLASH MEMORY TYPE : MULTI-LEVEL CELL (MLC)
FORM FACTOR : 3.5 LFF
INTERFACE : SATA3.5 inch
FEATURES : DIGITALLY SIGNED FIRMWARE, HPE SMARTSSD WEAR GAUGE
HEIGHT : 0.3 IN
BUNDLED WITH : HPE LOW PROFILE CONVERTER
PERFORMANCE:
DRIVE WRITES PER DAY (DWPD) : 1
DRIVE TRANSFER RATE : 600 MBPS (EXTERNAL)
INTERNAL DATA RATE : 500 MBPS (READ) / 465 MBPS (WRITE)
4KB RANDOM READ : 60000 IOPS
4KB RANDOM WRITE : 30000 IOPS
MAXIMUM 4KB RANDOM WRITE : 30000 IOPS
MAXIMUM 4KB RANDOM READ : 64000 IOPS
AVERAGE LATENCY : 60 µs
EXPANSION & CONNECTIVITY:
INTERFACES : 1 X SATA 6Gb/s
COMPATIBLE BAY : 3.5 LFF
