872507-001 Technical Specifications
HPE 800GB SAS 12GBPS 3.5inch LFF Hot Swap SCC Mixed USE Digitally Signed Firmware Solid State Drive
MAIN SPECIFICATIONS:
Product Description : Hpe Mixed Use – Solid State Drive – 800 GB – SAS 12GB/S
Type : Solid State Drive (SSD) – Hot Swap
Capacity : 800GB
Nand Flash Memory Type : Multi-Level Cell (MLC)
Form Factor : 3.5 inch LFF
Interface : SAS 12Gb/s
Data Transfer Rate : 1.2 GBPS
Features : 3 Dwpd, Digitally Signed Firmware
Dimensions (WXDXH) : 0.6 In
Bundled With : HPE Smart Carrier Converter
Designed For : Proliant Dl120 Gen9, Dl120 Gen9 Entry, Dl160 Gen9, Dl160 Gen9 Base, Dl160 Gen9 Entry, Dl160 Gen9 Performance, Dl360 Gen10, Dl360 Gen10 Base, Dl360 Gen10 Entry, Dl360 Gen10 High Performance, Dl360 Gen10 Performance, Dl380 Gen9, Dl380 Gen9 Base, Dl380 Gen9 Entry, Dl380 Gen9 High Performance, Dl380 Gen9 Performance, Dl380 Gen9 Scale-Up Sap Hana Tailored Datacenter Integration Compute Block, Dl380 Gen9 Special, Dl560 Gen9, Dl560 Gen9 Base, Dl560 Gen9 Entry, Dl560 Gen9 Performance (2.5), Ml350 Gen9 (2.5), Ml350 Gen9 Base (2.5), Ml350 Gen9 Entry (2.5), Ml350 Gen9 Performance (2.5), Ws460c Gen9 (2.5), Ws460c Gen9 Graphics (2.5), Ws460c Gen9 Graphics Expansion (2.5), Xl190r Gen9 (2.5)
EXTENDED SPECIFICATIONS:
Device Type : Solid State Drive – Hot – Swap
Capacity : 800 GB
Nand Flash Memory Type : Multi-Level Cell (MLC)
Form Factor : 3.5 LFF
Interface : SAS 12GB/S
Features : 3 DWPD, Digitally Signed Firmware
Height : 0.6 In
Bundled With : HPE Smart Carrier Converter
PERFORMANCE:
Drive Transfer Rate : 1.2 GBPS (External)
Internal Data Rate : 1075 MBPS (Read) / 1025 MBPS (Write)
4kb Random Read : 120000 IOPS
4kb Random Write : 90000 IOPS
