870761-K21 Technical Specifications
HPE 900GB 15kRPM 3.5in DS SAS-12G LPC Enterprise G10 HDD
General
Device Type: Hard Drive – Hot Swap
Capacity: 900GB
Form Factor: 3.5 inch LFF Low Profile
Interface: SAS 12Gb/s
Bytes per Sector: 512
Drive Technology (Fill): Air
Format Type: 512n
Carrier Type: Low Profile Carrier Converter (LPCC)
Workload: Enterprise
Features: Advanced format 512n, Dual Port, Digitally Signed Firmware
Bundled with: HPE Low Profile Carrier Converter
Performance
Drive Transfer Rate (External): 12 Gb/sec
Drive Rotation Speed: 15000 RPM
Average Seek Time: 2.72 ms
Max Seek Time: 5.36 ms
Track-to-Track Seek Time: 0.22 ms
OD Media Rate, Max Sequential Throughput (MiB/s): 295 MiB/s
128Kib Random Rd (IOPs): 235 IOPs
128Kib Random 70% RD / 30% WT (IOPs): 235 IOPs
128Kib Random 50% RD / 50% WT (IOPs): 235 IOPs
Expansion & Connectivity
Interfaces: 1 x SAS 12 Gb/s
Compatible Bay: 3.5″ LFF
Power
Idle Time: 4.70 Watts
Random R/W: 6.10 Watts
Sequential Read: 6.30 Watts
Sequential Write: 6.40 Watts
Dimensions
Width: 4.20 inch
Depth: 6.20 inch
Height: 1.03 inch
