844934-S01 Technical Specifications
HP ML150 G9 E5 2620V3 LFF US SVR/S BUY.
GENERAL INFORMATION :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 844934-S01
Product Name: HP Proliant ML150 Gen9 – 5u Tower Mount Server (S-Buy)
PROCESSOR & CHIPSET :
CPU : Intel Xeon E5-2620v3 / 2.4 GHZ
Max Turbo Speed : 3.2 Ghz
Number Of Cores : 6 Core
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Chipset Type : Intel C610
CACHE MEMORY :
Cache Memory Type : L3 Cache
Installed Size : 15mb
Cache Per Processor : 15 Mb
MEMORY :
Installed Size : 8 Gb / 256 Gb (Max)
Technology : Ddr4 Sdram – Advanced Ecc
Memory Speed : 1866 Mhz
Memory Specification Compliance : Pc4-17000
Form Factor : Dimm 288-Pin
RAM Slots: 16 x DDR4 RAM Slots
Features : Registered, Online Spare Memory, Quad Channel Memory Architecture, Hp Smartmemory
Configuration Features : 1 X 8 Gb
Ram Supported : Pc4-17000 – 256 Gb – Load-Reduced ¦ Pc4-17000 – 256 Gb – Registered
STORAGE:
Hard Drive : None
Optical Drive : None
STORAGE CONTROLLERS:
Type : 1 X Raid
Controller Interface Type : Sata 6gb/S
Storage Controller Name : Hp Dynamic Smart Array B140i
Channel Qty : 10
Raid Level : Raid 0, Raid 1, Raid 5, Raid 10
GRAPHICS CONTROLLERS :
Graphics Processor : No Graphics
NETWORK & COMMUNICATION:
Ethernet Ports : 2 X Gigabit Ethernet
Ethernet Controller : Hp 350i
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
POWER DESCRIPTION :
Device Type : Power Supply – Hot Plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (With Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Nominal Voltage : Ac 120/230 V ( 50/60 Hz )
Power Provided : 900 Watt
