Refurbished 7613-S323B-8G-P Technical Specifications
Cisco 7613 Chassis, 13-slot, SUP32-8GE-3B, PS
Device Type: Router – with Cisco Supervisor Engine 32 with 8 ports Gigabit Ethernet, PFC3B, and MSFC2A
Enclosure Type: Rack-mountable – modular – 18U
Connectivity Technology: Wired
Model Cisco 7613
Product Type: Router Chassis
Router Bundle
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Routing Protocol: IGMP, PIM-SM, PIM-DM, IGMPv3, GRE, PIM-SSM, Multiprotocol BGP
Remote Management Protocol: SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3
Features: DHCP support, NAT support, VPN support, ARP support, MPLS support, VLAN support, IPv6 support, Access Control List (ACL) support
Compliant Standards: IEEE 802.3, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3ak, NEBS level 3, FCC Class A certified, CISPR 22 Class A, EN 60950, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, AS/NZ 3548 Class A, CSA C22.2 No. 60950-00, ICES-003 Class A
RAM: 512 MB (installed) / 1 GB (max)
Flash Memory: 256 MB (installed) / 1 GB (max)
Expansion / Connectivity
Interfaces 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ USB 2.0: 1 x 4 pin USB Type A ¦ USB 2.0: 1 x 4 pin USB Type B ¦ 8 x SFP (mini-GBIC)
Expansion Slots 13 (total) / 12 (free) x expansion slot
Installed Modules Qty (Max) 1 (installed) / 13 (max)
Power
Power Device Internal power supply – hot-plug
Power Redundancy Yes
Installed Qty 1 (installed) / 2 (max)
Miscellaneous
Rack Mounting Kit Included
Dimensions & Weight
Width 16.7 in
Depth 17.6 in
Height 32.4 in
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 10 – 85%
