700513905 Technical Specifications
Avaya Vantage K175 Dual Port with Camera
IP Telephony
Network Protocols :DNS, HTTP, HTTPS, RTCP, RTP, SNTP, SRTCP, SRTP, TCP
Video Codecs :H.264
Voice Codecs :G.711, G.722, G.726, G.729, Opus
VoIP Protocols :RTCP, RTP, SIP, SRTCP, SRTP
Display
Diagonal Size (metric) :20.3 cm
Image Aspect Ratio :16:10
Projector Monitor Features :Capacitive touch screen, Foldable stand
Audio Input
Form Factor :Integrated
Type :Microphone
Cabinet
Chassis Built-in Devices :16GB flash, Camera, Microphone, Speaker
Header
Brand :Avaya
Manufacturer :Avaya Phone Systems
Model :K175
Packaged Quantity :1
Product Line :Avaya Vantage
Interface Provided
Connector Type :Mini-phone 3.5 mm
Type :Audio
Connector Type :RJ-45
Qty :2
Type :Network
Connector Type :RJ-9
Qty :1
Type :Headset
Type :Handset
Type :USB-C
Miscellaneous
Color :Cobalt black
Compliant Standards :IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Modem
Data Compression Protocol :G.711, G.722, G.726, G.729, H.264
Digital Signaling Protocol :SIP
Features :Message waiting indicator
Networking
Compliant Standards :Bluetooth 4.2, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Connectivity Technology :Wired, Wireless
Data Link Protocol :Bluetooth 4.2 LE, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features :Access Point operational mode, DiffServ Code Point (DSCP) support, Magnetic switch hook, Mechanical camera shutter, PoE+, Power over Ethernet (PoE), Quality of Service (QoS), Security lock slot (cable lock sold separately), VLAN support, Wall mountable
Network Transport Protocol :DHCP, DNS, RTCP, RTP, TCP/IP
Type :Network adapter
Power Device
Form Factor :External
Type :Power adapter
Software
Type :Google Play
System Requirements
Min Operating System :Android 8.0 (Oreo)
Video Input
Color Support :Color
Form Factor :Integrated
Type :Digital video camera
Dimensions & Weight
Weight :28.22 oz
Display (Projector)
Diagonal Size :8 in
Max Resolution :1280 x 800
System
Conferencing System Type :Video conferencing device
