Refurbished 696731-001 Technical Specifications
HP Proliant Dl580 G7 Base Models 2x Intel Xeon 8 Core E7 4830 2.13GHz 64gb Ddr3 Sdram Dvd Rom P410i With 512mb Fbwc Sas Sata Raid.
GENERAL INFORMATION :
Manufacturer: Hewlett Packard
Manufacturer Part Number: 696731-001
Product Name: Proliant Dl580 Gen7 4u Rack Mount Base Model
PROCESSOR & CHIPSET :
Processor Type: Intel Xeon E7-4830 / 2.13GHz
Multi-Core Technology: 8 Core
64-Bit Computing: Yes
Installed Qty: 2/
Max Supported Qty: 4
Chipset Type: Intel 7500
CACHE MEMORY :
Cache Memory Type: L3 Cache
Installed Size: 48 Mb
Cache Per Processor: 24 Mb
MEMORY :
Installed Ram Size: 64 Gb
Maximum Ram Size : 2 Tb
Technology: Ddr3 Sdram – Advanced Ecc
Memory Speed: 1333 Mhz
Memory Specification Compliance: Pc3-10600
Form Factor: Dimm 240-Pin
Features: Registered, Memory Mirroring, Online Spare Memory
Configuration Features: 8 X 8 Gb
STORAGE :
Hard Drives : None Ship Standard
Internal Storage : Up To 8.0tb Of Internal Storage (Sff Sas)
Optical Drive : Hp Slim Sata Dvd Rom Optical Drive
STORAGE CONTROLLERS :
Storage Controller Type: 1 X Raid – Integrated – Pci Express 2.0 X4
Controller Interface Type: Serial SAta-300 / Sas 2.0
Storage Controller Name: Embedded Hp Smart Array P410i/512 Mb Fbwc Controller
Raid Level: Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
Buffer Size: 512 Mb
DISPLAY & GRAPHICS :
Graphics Controller Type: Integrated
Graphics Processor: Ati Es1000
Video Memory: 64 Mb
Max Resolution : 1280 X 1024 X 16m Color
NETWORK & COMMUNICATION :
Networking Type: Integrated
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller : Hp 331i
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 3
Features : Wake On Lan (Wol), Pxe Suppor
POWER DESCRIPTION :
Device Type: Power Supply – Hot Plug
Power Redundancy: Yes
Installed Qty: 2
Max Supported Qty: 4
Voltage Required: Ac 120/230 V ( 50/60 Hz )
