Refurbished 668813-001 Technical Specifications
HP Proliant Dl360e G8 1x Intel Xeon Qc E5-2403/1.8GHz 10MB L3 Cache 4GB RAM Matrox G200 4x Gigabit Ethernet 1u Rack Server.
General Information :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 668813-001
Product Name : Proliant Dl360e Gen8 1u Rack Mount
Processor & Chipset :
Processor Type : Intel Xeon E5-2403 / 1.8ghz
Number Of Cores : Quad-Core ( 4 core)
Sockets Supported : Lga1356
64-Bit Computing : Yes
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Processor Main Features :
Hyper-Threading Technology,
Intel Quickpath Interconnect,
Intel Turbo Boost Technology 2
Chipset Type : Intel C600
Cache Memory :
Installed Size : L3 Cache – 10 Mb
Cache Per Processor : 10 Mb
Memory :
Installed Size : 4 Gb
Maximum Size : 192 Gb
Technology : Ddr3 Sdram
Memory Speed : 1333 Mhz
Memory Specification Compliance : Pc3-10600
Form Factor : Lrdimm 240-Pin
Features : Load-Reduced Dimm (Lrdimm)
Configuration Features : 1 X 4 Gb
Storage & Storage Controller :
Storage Hard Drive : None Ship Standard, Includes 7 Sff Hard Drive Blanks
Internal Storage : 8 Sff Hdd 8 Bays
Storage Controller Type : 1 X Raid – Integrated – Pci Express 2.0 X4
Controller Interface Type : Sata-600 / Sas 2.0
Storage Controller Name : Hp Dynamic Smart Array B320i
Channel Qty : 8
Raid Level : Raid 0, Raid 1, Raid 10
Display & Graphics Controllers :
Graphics Controller Type : Integrated
Graphics Processor : Matrox G200
Network & Communication :
Networking Type : Integrated
Interface (Bus) Type : Pci Express 2.0 X4
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller : Hp Ethernet 1gb 4-Port 366i Adapter
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : Snmp, Ipmi 2.0, Smash Clp
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol), Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab, Ieee 802.1as, Ieee 802.3az
Expansions & Connectivity :
Expansion Bays Total (Free) :
1 (Total) / 1 (Free) X External
8 (Total) / 8 (Free) X Hot-Swap – 2.5in Sff
Expansion Slots Total (Free) :
12 (Total) / 11 (Free) X Memory – Lrdimm 240-Pin
2 (Total) / 1 (Free) X Cpu
1 (Total) / 1 (Free) X Pcie 3.0 X16 – Half-Length, Full-Height
1 (Total) / 1 (Free) X Pcie 2.0 X8 – Low-Profile ( X4 Mode )
1 (Total) / 1 (Free) X Sd Card
Interfaces & Ports :
2 X Display / Video ( 1 Front, 1 Rear )
4 X Lan (Gigabit Ethernet)
6 X Usb 2.0 ( 2 Front, 4 Rear )
1 X Hp Ilo
1 X Serial
Power Device :
Device Type : Power Supply – Hot-Plug
Power Redundancy : Yes
Power Redundancy Scheme : 1+1
Installed Qty : 1
Max Supported Qty : 2
Voltage Required : Ac 120/230 V ( 50/60 Hz )
Power Provided : 460 Watt
80 Plus Certification : 80 Plus Gold
