Refurbished 647339-B21 Technical Specifications
HP Proliant Dl120 G7 CTO Chassis (Lff) Intel C200 Series Chipset With No CPU, NO RAM, NC112I Gigabit Server Adapter, Smart Array B110I SATA Raid Controller 1u Rack Server.
GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 647339-B21
Product Name: Proliant Dl120 G7 – 1u Rack Mount (Cto Model)
PROCESSOR & CHIPSET:
Cpu : No Cpu
Max Cpu Qty : 1
Chipset : Intel C200 Series
Upgradability: Upgradable
MEMORY:
Installed Ram Size: 0 Mb / 16 Gb (Max)
Technology: Ddr3 Sdram
Form Factor: Dimm 240-Pin
STORAGE :
Hard Drive: None.
Optical Drice : None.
STORAGE CONTROLLER :
Type : 1 X Sata
Controller Interface Type : Sata 3gb/S
Storage Controller Name : Smart Array B110i
Channel Qty : 4
Raid Level : Raid 0, Raid 1, Raid 10
NETWORK & COMMUNICATION :
Type : Integrated
Interface (Bus) Type : Pci Express 2.0 X1
Ethernet Ports : 2 X Gigabit Ethernet
Ethernet Controller : 2 X Hp Nc112i
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : Ipmi 2.0
Remote Management Controller : Integrated Lights-Out 3
Features : Wake On Lan (Wol), Acpi Support, Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 801.1p
EXPANSION & CONNECTIVITY :
Expansion Bays Total (Free) :
1 (Total) / 1 (Free) X Front Accessible – 5.25 Slim Line
4 (Total) / 4 (Free) X Hot-Swap – 3.5 Inch Lff
Expansion Slots Total (Free) :
1 (Total) / 1 (Free) X Pci Express 2.0 X8 – Low-Profile ( X4 Mode )
1 (Total) / 1 (Free) X Pci Express 2.0 X16 – Full-Length, Full-Height
4 (Total) / 4 (Free) X Memory – Dimm 240-Pin
1 (Total) / 1 (Free) X Processor
Interfaces & Ports:
1 X Serial
1 X Display / Video
6 X Usb 2.0 ( 2 Front, 4 Rear )
1 X Lan (Gigabit Ethernet)
1 X Management (Nic)
