646904-001 Technical Specifications
HP Proliant Dl360p G8 2 X Xeon E5-2650 2 GHz 32 GB DDR3 SDRAM 0 HDD RAID Array P420i/2GB Hot Plug 8 SFF 1GB 4-Port 331flr Ethernet Adapter Hot Plug 2 X 460w Ps 5u Rack Server.
GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 646904-001
Product Name: Proliant Dl360p G8 – 2 Way 1u Rack Mount (Performance Model)
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5-2650/ 2 Ghz
Multi-Core Technology: Octa-Core (8 Core)
64 Bit Computing: Yes
Installed Qty: 2
Max Supported Qty: 2
Upgradability: Upgradable
Chipset Model: Intel C600
CACHE MEMORY:
Type: L3 Cache
Installed Size: 40 Mb
Cache Per Processor: 20 Mb
MEMORY:
Installed Ram Size: 32 Gb / 384 Gb (Max)
Technology: Ddr3 Sdram
Form Factor: Dimm 240-Pin
Features: Registered, Quad Channel Memory Architecture, Hp Smartmemory
Configuration Features: 4 X 8 Gb
RAM SUPPORTED :
Pc3-12800 – 384 Gb – Registered
Pc3-10600 – 768 Gb – Load-Reduced
Pc3-10600 – 128 Gb – Unbuffered – Advanced Ecc
Pc3-10600 – 384 Gb – Hypercloud
STORAGE & STORAGE CONTROLLERS:
Hard Drive: None
Optical Drive Type : No
Memory Card Reader: Yes
Supported Flash Memory Cards: Secure Digital (Sd) Car
Storage Controller Type: 1 X Raid – Plug-In Card – Pci Express 3.0 X8
Controller Interface Type: Serial SAta-600 / Sas 2.0
Storage Controller Name: Smart Array P420i With 2gb Fbwc
Raid Levels: Raid 0, Raid 1, Raid 5, Raid 10, Raid 50
Buffer Size: 2 Gb
DISPLAY & GRAPHICS:
Graphics Controller Type : Integrated
Graphics Processor : Matrox G200
Video Interfaces : Vga
NETWORK & COMMUNICATION:
Networking: Network Adapter – Integrated
Ethernet Ports: 4 X Gigabit Ethernet
Ethernet Controller(S): Hp 331flr
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol: Ipmi 2.0, Smash Clp
Remote Management Controller: Integrated Lights-Out 4
Features: Wake On Lan (Wol), Pxe Support
Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3ad (Lacp)
POWER DESCRIPTION:
Device Type: Power Supply – Hot-Plug
Power Redundancy: Optional
Power Redundancy Scheme: 1+1 (With Optional Power Supply)
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: Ac 120/230 V ( 50/60 Hz )
Power Provided: 460 Watt
pDevice Type: Power Supply – Hot Plug
