644568-S01 Technical Specifications
HP Proliant BL460C G7 1x Intel Xeon E5649 Hc 2.53GHZ 12 GB Ram SAS SATA 2 X 10 Gigabit Ethernet 2 Way Blade Server.
GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 644568-S01
Product Name: Proliant Bl460c G7 2-Way Blade Server
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5649 / 2.53 Ghz
Multi-Core Technology: 6 Core (Hexa-Core)
64-Bit Computing: Yes
Installed Qty: 1
Max Supported Qty: 2
Upgradability: Upgradable
Chipset Type: Intel 5520
CACHE MEMORY:
Type: L3 Cache
Installed Size: 12 Mb
Cache Per Processor: 12 Mb
MEMORY:
Installed Ram Size: 12 Gb / 192 Gb (Max)
Technology: Ddr3 Sdram
Memory Speed: 1333 Mhz
Memory Specification Compliance: Pc3-10600
Form Factor: Dimm 240-Pin
Features: Registered
RAM SUPPORTED:
PC3-8500 – 384 GB – REGISTERED
PC3-10600 – 48 GB – UNBUFFERED – ECC
PC3-10600 – 192 GB – REGISTERED
STORAGE:
Hard Drive: None.
STORAGE CONTROLLERS:
Storage Controller Type: 1 X SAS Serial Attached Scsi 2 – Integrated – Pci Express X4
Controller Interface Type: Serial SAta-300 / Sas 2.0
Storage Controller Name: Smart Array P410i
Raid Level: Raid 0, Raid 1
DISPLAY & GRAPHICS:
Graphics Controller Type: Integrated
Graphics Processor: Matrox Mga G200
NETWORK & COMMUNICATION:
Networking: Network Adapter – Pci Express 2.0 X8 – Integrated
Ethernet Ports: 2 X 10 Gigabit Ethernet
Ethernet Controller(S): Hp Nc553i
Data Link Protocol: Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol: Snmp, Ipmi 2.0
Remote Management Controller: Integrated Lights-Out 3
Features: Wake On Lan (Wol)
Compliant Standards: Ieee 802.1q, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.3ap
