642121-001 Technical Specifications
HP Proliant Dl380p Gen8 E5-2609 2.40G 10MB 1P 4GB 2U RM Entry Svr.
GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 642121-001
Product Name: Proliant Dl380p G8 – 2u Rack Mount (Entry Model)
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5-2609 / 2.40 Ghz
Multi-Core Technology: Quad-Core (4 Core)
64 Bit Computing: Yes
Installed Qty: 1
Max Supported Qty: 2
Upgradability: Upgradable
Chipset Model: Intel C600
CACHE MEMORY:
Type: L3 Cache
Installed Size: 10 Mb
Cache Per Processor: 10 Mb
MEMORY:
Installed Size: 4 Gb / 384 Gb (Max)
Technology: Ddr3 Sdram
Memory Speed: 1333 Mhz
Memory Specifications Compliance: Pc-3 10600
Form Factor: Dimm 240-Pin
Number Of Total Memory Slots: 24 Ddr3 Slots
Features: Registered
STORAGE:
Hard Drive : None
Optical Drive : None
Memory Card Supported: Secure Digital (Sd) Card
STORAGE CONTROLLERS:
Storage Controller Type : 1 X Raid – Plug-In Card – Pci Express 3.0 X8
Controller Interface Type : Serial SAta-300 / Sas 2.0
Storage Controller Name : Smart Array P420i/Zm
Raid Level : Raid 0 Raid 1 Raid 10
DISPLAY & GRAPHICS:
Graphics Type: Integrated
Graphics Controller Model: Matrox G200
NETWORK & COMMUNICATION:
Type : Hp Ethernet 1gb 4-Port 331flr Adapter
Networking: Network Adapter – Integrated
Ethernet Ports: 4 X Gigabit Ethernet
Data Link Protocol: Ethernet Fast Ethernet Gigabit Ethernet
Remote Management Controller: Integrated Lights-Out 4
Features: Wake On Lan (Wol), Pxe Support
Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3ad (Lacp)
POWER DESCRIPTION:
Device Type: Power Supply
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 1
Max Supported Qty: 2
Voltage Required: Ac 120/220 V
Power Provided: 460 Watt
