642106-001 Technical Specifications
HP Proliant Dl380p G8 2u Rack Server 2 X Intel Xeon E5-2650 2GHz.
GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 642106-001
Product Name: Proliant Dl380p G8 2u Rack Mount Performance Server
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5-2650
Number Of Processors Installed: 2
Number Of Processors Supported: 2
Multi-Core Technology: Octa-Core (8 Core)
Quickpath Interconnect: 8 Gt/S
64 Bit Computing: Yes
Upgradability: Upgradable
Processor Main Features: Hyper Threading Technology
Chipset Model: Intel C600
CACHE MEMORY:
Cache Memory Type: L3 Cache
Installed Size: 40 MB
Cache Per Processor: 20 MB
RAM:
Installed Size: 32 GB
Max Supported Size: 768 GB
Technology: Ddr3 Sdram
Memory Standard: Ddr3-1600/Pc3-12800
Number Of Total Memory Slots: 24 Ddr3 Slots
Memory Card Reader: Yes
Memory Card Supported: Secure Digital (Sd) Card
Features: Registered
Configuration Features: 4 X 8 Gb
STORAGE:
Hard Drive: None
Max Internal Storage:
Standard: 8 Sff Sas/Sata Hdd Bays
Optional: +8 Sff (Total Of 16) Sff Sas/Sata Hdd Bays
Optical Drive Type: Dvd-Writer
STORAGE CONTROLLERS:
Controller Type: 1 X Raid-Plug In Card – Pci Express 3.0 X8
Controller Interface Type: Serial Ata-300 / Sas 2.0
Storage Controller Name: Smart Array P420i
Raid Level: Raid 0 Raid 1 Raid 5 Raid 10 Raid 50
Buffer Size: 2 Gb
DISPLAY & GRAPHICS CONTROLLER:
Graphics Type: Integrated
Graphics Controller Model: Matrox G200
NETWORKING:
Networking: Network Adapter, Integrated
Ethernet Ports: 4 X 10 Gigabit Ethernet
Ethernet Controller(S): Hp 331flr
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller: Integrated Lights-Out 4
Features: Wake On Lan (Wol), Pxe Support
Compliant Standards:
Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab
Ieee 802.1p, Ieee 802.3ad (Lacp)
POWER DESCRIPTION:
Device Type: Power Supply, Hot Plug
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: Ac 120/230 V ( 50/60 Hz )
Power Provided: 750 Watt
Compliant Standards:
