640996-B21 Technical Specifications
HP Proliant Bl420c G8 Cto Chassis With No Cpu, No Ram, 2x Sas/Sata/Ssd Hard Drive Bays, 10gb Flexible Lom, 2 Way Blade Server.
General Information :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 640996-B21
Product Name : Proliant Bl420c G8 Blade Server
Processor & Chipset :
Processor Type : Intel Xeon E5-2400 Series Processors
64-Bit Computing : Yes
Installed Qty : No Cpu
Max Supported Qty : 2
Upgradability : Upgradable
Chipset Type : Intel C600
Memory :
Installed Size : None
Maximum Size : 384 Gb
Technology : Ddr3 Sdram
Form Factor : Dimm 240-Pin
Storage & Storage Controller :
Hard Drive : None
Hard Drive Support : Hp 1.6tb And 800gb 12g Sas Value Endurance Sff 2.5in Sc Enterprise Value Solid State Drives
Storage Controller Type : 1 X Serial Attached Scsi 2 – Integrated – Pci Express 3.0 X8
Controller Interface Type : Serial SAta-600 / Sas 2.0
Storage Controller Name : Hp Dynamic Smart Array B320i
Channel Qty : 8
Raid Level : Raid 0, Raid 1, Raid 10
Display & Graphics Controllers :
Graphics Controller Type : Integrated
Graphics Processor : Matrox G200
1280 X 1024 (32 Bpp)
1920 X 1200 (16 Bpp)
Hp Ilo 4 On System Management Memory
16 Mb Flash
256 Mb Ddr 3 With Ecc (112 Mb After Ecc And Video)
Network & Communication :
Networking : Network Adapter – Pci Express 2.0 X8 – Integrated
Ethernet Ports : 10 Gigabit Ethernet
Data Link Protocol : Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol : Snmp, Ipmi 2.0, Smash Clp
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol)
Compliant Standards : Ieee 802.1q, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.3ap
Expansions & Connectivity :
Expansion Bays Total (Free) :
2 (Total) / 2 (Free) X Hot-Swap – 2.5in Sff
Expansion Slots Total (Free) :
2 (Total) / 2 (Free) X Processor
12 (Total) / 12 (Free) X Memory – Dimm 240-Pin
1 (Total) / 0 (Free) X Flexiblelom
1 (Total) / 1 (Free) X Expansion Slot ( X16 Mode )
1 (Total) / 1 (Free) X Expansion Slot ( X8 Mode )
1 (Total) / 1 (Free) X Microsdhc
Interfaces & Ports :
1 X Management – Hp Ilo – Rj-45
1 X Network – Ethernet 10gbase-Kr – Rj-45
