Refurbished 639830-005 Technical Specifications
HP PROLIANT DL380G7 X5675 2.53 2P 8GB SFF.
GENERAL INFORMATION:
Manufacturer : Hewlett Packard.
Manufacturer Part Number : 639830-005
Product Name : Proliant Dl380 G7 2u Rack Mount (S-Buy) Server.
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon Processor X5675 (3.06ghz, 12mb L3 Cache, 95w)
Multi-Core Technology : Hexa-Core ( 6 core)
Installed Qty : 2
Max Supported Qty : 2
Upgradability : Upgradable.
64-Bit Computing : Yes.
Mainboard Chipset Type : Intel 5520
CACHE MEMORY :
Cache Memory Type : L3 Cache.
Installed Size : 24 Mb.
Cache Per Processor : 12 Mb.
RAM :
Installed Size : 8 Gb.
Max Supported Size : 288 Gb.
Ram Technology : Ddr3 Sdram.
Memory Speed : 1333 Mhz.
Memory Specification Compliance : Pc3-10600
Form Factor : Dimm 240-Pin.
Features : Registered.
Configuration Features : 2 X 4 Gb
STORAGE & STORAGE CONTROLLER :
Hard Drive : None.
Optical Storage Type : Hp Slim Sata Dvd Rw.
Internal Storage :
8 Sff Sas/Sata Hdd Bays.
Storage Controller Type: 1 X Raid – Integrated – Pci Express 2.0 X4
Controller Interface Type: Serial Ata-300 / Sas 2.0
Storage Controller Name: Smart Array P410i With 1gb Fbwc
Raid Level: Raid 0, Raid 1, Raid 5, Raid 10, Raid 50
Buffer Size: 1 Gb
DISPLAY & GRAPHICS CONTROLLER :
Graphics Controller Type : Integrated.
Graphics Processor: Ati Es
Video Memory : 64 Mb.
Supported Resolution :
16 Bit Color: Maximum Resolution Of 1600 X 1200
32 Bit Color: Maximum Resolution Of 1280 X 1024
NETWORKING :
Networking : Network Adapter – Pci Express X4 – Integrated.
Ethernet Ports : 4 X Gigabit Ethernet.
Ethernet Controller : 2 X Hp Nc382i.
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet.
Remote Management Controller : Integrated Lights-Out 3
Features : Wake On Lan (Wol)
Compliant Standards :
Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab
Ieee 802.1p, Ieee 802.3ad (Lacp)
INTERFACES :
1 X Keyboard – Generic – 6 Pin Mini-Din (Ps/2 Style)
1 X Mouse – Generic – 6 Pin Mini-Din (Ps/2 Style)
1 X Serial 2x Display/Video-Vga-15 Pin Hd -Sub (Hd-15) ( 1 Front, 1 Rear) 4 X Usb – 4 Pin Usb Type A ( 2 Front, 2 Rear )
4 X Network – Ethernet 10base-T/100base-Tx/1000base-T – Rj-45
1 X Management – Hp Ilo – Rj-45
POWER DEVICE :
Power Device Type: Power Supply – Hot Plug
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: Ac 120/230 V ( 50/60 Hz )
Power Provided: 750 Watt
