Refurbished 638181-001 Technical Specifications
HP Proliant Ml350 G6 5u Tower Server 1 X Intel Xeon E5645 2.4GHz.
General information :
Manufacturer : Hewlett packard
Manufacturer part number : 638181-001
Product name : proliant ml350 g6 2-way 5u tower server
Processor & chipset :
Processor type : intel xeon e5645 / 2.4ghz
Multi-core technology : 6 core
64-bit computing : yes
Installed qty : 1
Max supported qty : 2
Upgradability : upgradable
Processor main features :
Hyper-threading technology,
Intel turbo boost technology
Chipset type : intel 5520
Cache memory :
Cache memory type : l3 cache
Installed size : 12 mb
Cache per processor : 12 mb
Memory :
Installed size : 6 gb
Maximum memory : 288 gb
Technology : ddr3 sdram – advanced ecc
Memory speed : 1333 mhz
Memory specification compliance : pc3-10600
Form factor : dimm 240-pin
Features : registered
Configuration features : 3 x 2 gb
Ram supported : pc3-8500 – 192 gb – registered pc3-10600 – 288 gb – registered pc3-10600 – 48 gb – unbuffered – ecc
Storage & storage controller :
Hard drive : none
Optical device : dvd-rom – serial ata
Storage controller type : 1 x raid – integrated – pci express 2.0 x4
Controller interface type : serial Sata-300 / sas 2.0
Storage controller name : smart array p410i
Raid level : raid 0, raid 1, raid 5, raid 10, raid 50
Buffer size : 256 mb
Display & graphics controllers :
Graphics controller type : integrated
Graphics processor : ati rn50
Video memory :
16 bit color: maximum resolution of 1600 x 1200
32 bit color: maximum resolution of 1280 x 1024
Network & communication :
Networking : network adapter – pci express x4 – integrated
Ethernet ports : 2 x gigabit ethernet
Ethernet controller(s) : hp nc326i
Data link protocol : ethernet, fast ethernet, gigabit ethernet
Remote management controller : integrated lights-out 2
Features : wake on lan (wol), acpi support, pxe support
Compliant standards : ieee 802.3, ieee 802.3u, ieee 802.3ab
Expansions & connectivity :
Expansion bays total (free) :
5 (total) / 4 (free) x front accessible – 5.25in x 1/2h
8 (total) / 8 (free) x hot-swap – 2.5in sff
Expansion slots total (free) :
1 (total) / 1 (free) x pci express 2.0 x16-full-length, full-height(x8 mode)
1 (total) / 1 (free) x pci express 2.0 x8-full-length, full-height
4 (total) / 4 (free) x pci express 2.0 x8-full-length, full-height ( x4 mode )
18 (total) / 15 (free) x memory – dimm 240-pin
2 (total) / 1 (free) x processor
Interfaces & ports :
1 x display / video – vga – 15 pin hd d-sub (hd-15)
1 x keyboard – generic – 6 pin mini-din (ps/2 style)
1 x mouse – generic – 6 pin mini-din (ps/2 style)
1 x serial – rs-232 – 9 pin d-sub (db-9)
2 x network – ethernet 10base-t/100base-tx/1000base-tx – rj-45
1 x management – hp ilo – rj-45
4 x hi-speed usb – 4 pin usb type a ( 2 front, 2 rear )
Power device :
Device type : power supply – hot-plug
Power redundancy : optional
Power redundancy scheme : 1+1 (with optional power supply)
Installed qty : 1
Max supported qty : 2
Voltage required : ac 120/230 v ( 50/60 hz )
Power provided : 750 watt
