Refurbished 532075-005 Technical Specifications
HP Proliant DL180 G6 1X Xeon E5520 QC 2.26GHz 4GB RAM SAS SATA HP Smart Array P410 HP NC362I Gigabit Controller Rack Server.
GENERAL INFORMATION:
Manufacturer: Hewlett-Packard
Manufacturer Part Number: 532075-005
Product Name: Proliant Dl180 G6 2u Rack Mount Server
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5520 / 2.26 GHz
Multi-Core Technology: Quad-Core
64-Bit Computing: Yes
Installed Processor Qty: 1
Max Supported Qty: 2
Upgradability: Upgradable
Processor Sockets Supported: Lga1366
Chipset Type: Intel 5520
CACHE MEMORY:
Type: L3 Cache
Installed Size: 8 Mb
Cache Per Processor: 8 Mb
MEMORY:
Installed Ram Size: 4 Gb / 24 Gb (Max)
Technology: Ddr3 Sdram – Advanced Ecc
Memory Speed: 1333 Mhz
Memory Specification Compliance: Pc3-10600
Form Factor: Dimm 240-Pin
Features: Unbuffered
Configuration Features: 2 X 2 Gb
STORAGE:
Hard Drive: None.
Internal Storage:
14.0tb (14 X 1tb Hot Plug 3.5 Sata Hard Drives), Maximum
14.0tb (14 X 1tb Hot Plug 3.5 Sas Hard Drives), Maximum
Optical Storage Type: Dvd-Rw
STORAGE CONTROLLERS:
Storage Controllers Type: 1 X Raid – Plug-In Card – Pci Express 2.0 X8
Controller Interface Type: Serial Ata-150 / Sas
Storage Controller Name: Smart Array P410
Raid Level: Raid 0, Raid 1, Raid 10, Raid 50
Buffer Size: 256 Mb
DISPLAY & GRAPHICS:
Type: Integrated
Graphics Processor: Shared Video Memory (Uma)
Max Allocated Ram Size: 32 Mb
NETWORKING:
Networking: Network Adapter – Integrated
Ethernet Ports: 2 X Gigabit Ethernet
Ethernet Controller(S): Hp Nc362i
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
POWER DESCRIPTION:
Device Type: Power Supply
Voltage Required: Ac 120/230 V ( 50/60 Hz )
Power Provided: 750 Watt
