Refurbished 463-6117 Technical Specifications
Dell Poweredge R320 1X Xeon Quad-Core E5-2407-V2/2.4GHz, 1X 8GB DDR3 SDRAM, 1TB SAS Hot-Swap LFF HDD, DVD-Writer, 2X Gigabit Ethernet, 350W PS, 1U Rack Mountable Server.
GENERAL INFORMATION :
Manufacturer : Dell
Manufacturer Part Number : 463-6117
Product Name : Poweredge R320 1u Rack Server
PROCESSOR & CHIPSET :
CPU: Intel Xeon E5-2407V2 / 2.4GHz
Number Of Cores : 4-Core (Quad-Core)
Cpu Qty : 1
Max Cpu Qty : 1
Chipset Type : Intel C600
Cache Memory : L3 Cache
Cache Per Processor : 10 MB
MEMORY :
Installed Size : 8 GB / 192 GB (MAX)
Technology : DDR3 SDRAM – ECC
Memory Speed : 1600 MHz
Form Factor : DIMM 240-pin
Features : Unbuffered, Dual Rank
Configuration Features : 1 X 8 GB
STORAGE & STORAGE CONTROLLER :
Hard Drive Capacity : 1X 1TB
Interface Type : SATA 3GB/S
Spindle Speed : 7200 RPM
Storage Controller Type : 1 X SATA
Optical Drive Type : DVD-WRITER
DISPLAY & GRAPHICS CONTROLLER :
Graphics Controller : Matrox
Graphics Controller Model : G200
Video Memory : 16 MB
Video Interfaces : VGA
NETWORK & COMMUNICATION :
Ethernet Ports : 2 X Gigabit Ethernet
Ethernet Controller : Broadcom BCM5720
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : DMI 2.0, IPMI 2.0
Remote Management Controller : Intel Baseboard Management Controller (Bmc)
EXPANSIONS & CONNECTIVITY :
Expansion bays total (free) :
1 (Total) / 0 (Free) X External 5.25inch Slim Line
4 (Total) / 3 (Free) X Hot Swap 3.5inch
EXPANSION SLOTS TOTAL (FREE) :
1 (Total) / 0 (Free) X CPU
6 (TOTAL) / 5 (FREE) X DIMM 240-PIN
1 (TOTAL) / 1 (FREE) X PCIE 3.0 X16 – Full-Height ( Half-Length )
1 (TOTAL) / 1 (FREE) X PCIE 2.0 X8 – Half-Length, Low-Profile ( X4 Mode )
INTERFACES & PORTS :
2 X USB 2.0 ( 2 FRONT, 2 REAR )
1 X MANAGEMENT (NIC)
2 X VGA ( 1 FRONT, 1 REAR )
2 X LAN (GIGABIT ETHERNET)
1 X SERIAL
POWER DEVICE :
Device Type : Power Supply – Hot-Plug
Installed Qty : 1
Max Supported Qty : 1
Nominal Voltage : AC 120/230 V ( 50/60 HZ )
Power Provided : 350 WATT
