403-BBFH Technical Specifications
Dell 16GBPS Fiber Channel ISCSI Controller with 8GB
Manufacturer: Dell
MPN: 403-BBFH
Type: Controller
Controller Type: Fiber Channel
Interfaces: Dual 16GBPS Fiber Channel and ISCSI interfaces
Cache: 8GB memory
Data Transfer Rate: Up to 16GBPS
RAID Support: RAID levels 0, 1, 5, 6, 10, 50, 60
Form Factor: Low profile PCIe 3.0
Power Consumption: 30W (typical)
Temperature Range: Operating temperature range of 0°C to 55°C
Dimensions: 6.6″ x 2.7″ x 0.7″ (167.6mm x 68.6mm x 17.5mm)
Weight: 0.75lb (0.34kg)
