Refurbished 389831-405 Technical Specifications
HP ProLiant DL360 G4p – no CPU – Monitor
GENERAL
Packaged Quantity1
Recommended Usecorporate business, small business
Product Form Factor 1U Rack-mountable – 1U
Server Scalability2-way
Front Accessible Bays Qty1
Hot-Swap Bays Qty 4 Bays
HP ProLiant DL360 G4p
ManufacturerHP
PROCESSOR / CHIPSET
CPUNo CPU
Data Bus Speed800 MHz
Chipset Type Intel E7520
RAM
Features Online Spare Memory, registered
Upgrade Rule2 modules at a time
MEMORY
Max Supported Size12 GB
Form Factor DIMM 240-pin
Slots Qty6
Empty Slots6
STORAGE
Typenone
ENVIRONMENTAL PARAMETERS
Humidity Range Operating10 – 90%
Sound Emission50 dBA
STORAGE CONTROLLER (2ND)
Type1 x IDE – integrated
PROCESSOR
Max Supported Qty2
Upgradabilityupgradable
FLOPPY DRIVE
Typenone
MISCELLANEOUS
FeaturesQuickLock, administrator password, disk configuration lock, diskette I/O control, keyboard password, power-on password, serial port I/O control
Compliant StandardsACPI 1.0b
MONITOR
Monitor TypeNone.
NETWORKING
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
Form Factorintegrated
Compliant StandardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Interface (Bus) TypePCI-X / 66 MHz
Ethernet Ports2 x Gigabit Ethernet
Ethernet Controller(s)HP NC7782
Remote Management ControllerIntegrated Lights-Out Standard
GRAPHICS CONTROLLER
Form Factorintegrated
Graphics ProcessorATI RAGE XL
Video Memory8 MB SDRAM
Video InterfacesVGA
DIMENSIONS & WEIGHT
Width16.8 in
Depth27.8 in
Height1.7 in
PRINTER
EXPANSION / CONNECTIVITY
Bays1 (total) / 1 (free) x external 5.25″ Slim Line
4 (total) / 4 (free) x hot-swap 2.5″
PHYSICAL CHARACTERISTICS
Form Factorrack-mountable
Weight27.56 lbs
POWER
Typepower supply – hot-plug
Power Redundancyoptional
Power Redundancy Scheme1+1 (with optional power supply)
Installed Qty1
Max Supported Qty2
Min Operating Temperature50 °F
Max Operating Temperature95 °F
OPERATING SYSTEM / SOFTWARE
OS CertifiedMicrosoft Windows 2000 Server, Microsoft Windows Server 2003, Novell NetWare, Red Hat Linux, SuSe Linux, SunSoft Solaris, UnitedLinux
TypeDrivers & Utilities, HP Management Agents, HP Systems Insight Manager (HP SIM), SmartStart
