Refurbished 389823-001 Technical Specifications
HP ProLiant DL360 G4p – Xeon 3.6 GHz
GENERAL
Packaged Quantity1
Product Form Factor 1U Rack-mountable
Server Scalability2-way
Front Accessible Bays Qty1
Hot-Swap Bays Qty 4 Bays
Manufacturer HP
PROCESSOR / CHIPSET
CPU Intel Xeon 3.6 GHz
64-bit Computing Yes
Data Bus Speed800 MHz
Chipset Type Intel E7520
Processor Socket Socket 604
CACHE MEMORY
Installed SizeL2 cache – 2 MB
Cache Per Processor2 MB
RAM
Technology DDR2 SDRAM – Advanced ECC
Memory Speed400 MHz
Memory Specification CompliancePC2-3200
Featuresregistered
Upgrade Rule2 modules at a time
MEMORY
Max Supported Size12 GB
Form FactorDIMM 240-pin
Slots Qty6
Empty Slots 4 DDR2 Slots
STORAGE
RAID LevelRAID 0, RAID 0+1, RAID 1, RAID 5, RAID 6
Typenone
Read Speed24x
ENVIRONMENTAL PARAMETERS
Humidity Range Operating10 – 90%
Sound Emission50 dBA
STORAGE CONTROLLER
Interface Type Serial Attached SCSI (SAS)
Storage Controller Name Smart Array P600
Buffer Size256 MB
STORAGE CONTROLLER (2ND)
Type1 x SATA – integrated
Controller Interface TypeSerial ATA-150
Channel Qty2
PROCESSOR
Installed Qty1
Max Supported Qty2
Upgradabilityupgradable
FLOPPY DRIVE
Typenone
MISCELLANEOUS
FeaturesQuickLock, administrator password, disk configuration lock, diskette I/O control, keyboard password, power-on password
Compliant StandardsACPI 1.0b
MONITOR
Monitor TypeNone.
NETWORKING
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
Form Factorintegrated
Compliant StandardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Interface (Bus) TypePCI-X / 66 MHz
GRAPHICS CONTROLLER
Form Factorintegrated
Graphics ProcessorATI RAGE XL
Video Memory8 MB SDRAM
Video InterfacesVGA
DIMENSIONS & WEIGHT
Width16.8 in
Depth27.8 in
Height1.7 in
PRINTER
Typenone
EXPANSION / CONNECTIVITY
Bays1 (total) / 0 (free) x external 5.25″ Slim Line
4 (total) / 4 (free) x hot-swap 2.5″
Slots
