Refurbished 269786-001 Technical Specifications
HP proliant Ml350 G3 1 X Intel Xeon 2.4GHz 256MB RAM Ultra160 SCSI 48x Cd-Rom Fdd Gigabit Ethernet 5u Tower Server.
GENERAL INFORMATION :
Manufacturer: Hewlett Packard
Manufacturer Part Number: 269786-001
Product Name: Proliant Ml350 (Gen3) 5u Tower Server
Processor & Chipset :
Processor Type : Intel Xeon 2.4 Ghz
Installed Qty : 1
Max Supported Qty : 2
Upgradability : Upgradable.
Chipset Type : Serverworks Grand Champion Le
Data Bus Speed : 400 Mhz
CACHE MEMORY :
Cache Memory Type : L2 Cache – Advanced Transfer Cache.
Installed Size : 512 Kb
Cache Per Processor : 512 Kb
RAM :
Installed Size : 256 Mb
Max Supported Size : 8 Gb
Technology : Ddr Sdram – Ecc
Memory Speed : 266 Mhz
Memory Specification Compliance : Pc2100
Form Factor : Dimm 184-Pin
STORAGE CONTROLLERS :
Storage Controller Type(1st) : 1 X Scsi – Integrated – Pci 64
Controller Interface Type : Ultra160 Scsi
Channel Qty : 2
Storage Controller Type(2nd) : 1 X Ide – Integrated.
Controller Interface Type : Eide/Atapi
STORAGE :
Floppy Drive : 3.5in 1.44 Mb Floppy
Hard Drive : None.
Optical Storage Type : Cd-Rom – Ide
Read Speed : 48x
Media Load Type : Tray
DISPLAY & GRAPHICS CONTROLLER :
Graphics Controller Type : Pci – Integrated
Graphics Processor : Ati Rage Xl
Video Memory : 8 Mb Sdram
NETWORK CONTROLLER :
Networking : Network Adapter – Pci – Integrated.
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet.
Features : Wake On Lan (Wol)
EXPANSION / CONNECTIVITY:
Expansion Bays Total (Free):
6 ( 6 ) X Hot-Swap – 3.5in X 1/3h
3 ( 2 ) X Front Accessible – 5.25in X 1/2h
1 ( 0 ) X Front Accessible – 3.5in X 1/3h
Expansion Slots Total (Free):
4 ( 3 ) X Memory – Dimm 184-Pin
2 ( 1 ) X Processor – Socket 603
4 ( 4 ) X Pci-X / 100 Mhz 1 ( 1 ) X Pci
INTERFACES :
1 X Parallel – Ieee 1284 (Epp/Ecp) – 25 Pin D-Sub (Db-25)
1 X Serial – Rs-232 – 9 Pin D-Sub (Db-9)
1 X Mouse – Generic – 6 Pin Mini-Din (Ps/2 Style)
1 X Display & Video – Vga – 15 Pin Hd D-Sub (Hd-15)
1 X Keyboard – Generic – 6 Pin Mini-Din (Ps/2 Style)
2 X Usb – 4 Pin Usb Type A
1 X Network – Ethernet 10base-T/100base-Tx/1000base-T – Rj-45
POWER :
Device Type : Power Supply – Hot-Plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (With Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Voltage Required : Ac 120/230 V Ac 110/220 V ± 9% ( 50/60 Hz )
Power Provided : 500 Watt
