100-W3-0500-K1 Technical Specifications
EVGA 500 W3 80+ WHITE 500W 3 Year Warranty Power Supply
Brand: EVGA
Series: 500 W3
Model: 100-W3-0500-K1
Type: ATX12V / EPS12V
Maximum Power: 500 W
Fans: 1 x 120mm Sleeve Bearing
PFC: Active
Main Connector: 24Pin
+12V Rails: Single
PCI-Express Connector: 2 x 6+2-Pin
SATA Power Connector: 6
Haswell Support: Yes
Max PSU Length: 140 mm
Modular: Non-Modular
Efficiency: 80% Efficiency
Energy-Efficient: 80 PLUS Certified
Protection:
OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
Input Voltage: 100 – 240 V
Input Frequency Range: 50/60 Hz
Input Current: 7 – 3.5A
Output: +3.3V@18A, +5V@18A, +12V@40A, [email protected], +5Vsb@3A
MTBF: 100,000 Hours
Approvals:
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 3 2014 Requirement
Connectors:
1 x 24 Pin ATX
1 x 8pin (4+4) EPS (CPU)
2 x 8pin (6+2) PCIE
6 x SATA
3 x Four-Pin Peripheral
1 x Floppy
