0F27356 Technical Specifications
WD Ultrastar DC HC510 HUH721008AL5200 – hard drive – 8TB – SAS 12Gb/s
Header
Manufacturer :Hitachi Hard Drives
Brand :WD
Product Line :WD Ultrastar DC HC510
Model :HUH721008AL5200
Packaged Quantity :1
Storage
Type :Hard drive
Hard Drive
Hard Drive Type :Internal hard drive
Form Factor :3.5″
Form Factor (metric) :8.9 cm
Form Factor (Short) :3.5″
Form Factor (Short) (metric) :8.9 cm
Storage Interface :Serial Attached SCSI 3
Interface :Serial Attached SCSI 3
Capacity :8 TB
Average Seek Time :8.6 millisecond
Average Latency :4.16 millisecond
Data Transfer Rate :1.2 GBps
Spindle Speed :7200 RPM revolutions per minute
Buffer Size :256 megabyte, 256 megabyte
Bytes per Sector :512
Non-Recoverable Errors :1 per 10^15
Load / Unload Cycles :600,000
24×7 Operation :Yes
Features :24×7 continuous operation, Instant Secure Erase (ISE), Massive Scale Out (MSO), Rebuild Assist mode, Rotational Vibration Safeguard (RVS), HelioSeal, Filled with Helium, Perpendicular Magnetic Recording (PMR), Advanced format 512e, TCOptimized
Interface Provided
Interfaces :1 x SAS 12 Gb/s
Bay Required
Compatible Bay :3.5″
Power Consumption
Power Consumption :5.8 Watt (idle), 9.5 Watt (active)
Miscellaneous
MTBF :2,500,000 Hours
Dimensions & Weight
Width :4 inch
Depth :5.8 inch
Height :1 inch
Weight :23.28 ounce
