00J6384 Technical Specifications
IBM 2.50GHz 7.20GT/s QPI 15MB L3 Cache Intel Xeon E5-2430 v2 6 Core Processor Upgrade
Brand Intel
Part No. 00J6384
Processor Type Server
Processor Family E5-2400 v2
Series Xeon Processor
Core Model Type/ProcNo. E5-2430 v2
Processor Code Name Ivy Bridge EN
Core Stepping S1
Manufacturing Technology 22 nm
CPU ID String 306E4
# of Cores 6
# of Threads 12
Clock Speed 2.50 GHz
L3 Cache Size 15 MB
Front Side Bus / QuickPath Interconnect 7.20 GT/s
Thermal Power 80 Watts
VID Voltage Range 0.65-1.30V
CPU Socket Type LGA 1356
